LANRIN  in the research and development of advanced sensing devices, specifically Force, Torque, and Pressure Sensors, as well as Load Cells.  we are a worldwide supplier of sensors for such industries as Medical, Aerospace

MODEL: SPD

MODEL: SPD

Handheld 7 digit LCD display with peak, trough, net, overload and shunt cal indication.

Battery life of 450 hours in power save mode.

Keys for on/off, range select, peak/valley hold, and gross/net.

Single pass calibration (direct mV/V) with dual range for values such as kg and lb.

Easy to carry - weighing only 250 grams.

Waterproof IP65 NEMA4 battery powered.

Microprocessor based, allowing single pass calibration facility (direct mV/V).

TEDS enabled for automatic sensor calibration (IEEE1451 - template 33).

SPD (shown in main photo) the RS232 output option (shown in photo top left ) and photo bottom left showing optional black leather carry case with clear viewing window and shoulder strap for both versions Load Cell.

0.00
0.00


Handheld 7 digit LCD display with peak, trough, net, overload and shunt cal indication.

Battery life of 450 hours in power save mode.

Keys for on/off, range select, peak/valley hold, and gross/net.

Single pass calibration (direct mV/V) with dual range for values such as kg and lb.

Easy to carry - weighing only 250 grams.

Waterproof IP65 NEMA4 battery powered.

Microprocessor based, allowing single pass calibration facility (direct mV/V).

TEDS enabled for automatic sensor calibration (IEEE1451 - template 33).

SPD (shown in main photo) the RS232 output option (shown in photo top left ) and photo bottom left showing optional black leather carry case with clear viewing window and shoulder strap for both versions Load Cell.
